Crossover Frequency : 380Hz – 3.8kHz
Dimensions : H 740mm 29.1” W 330mm
13” D 465mm 18.3” – Stand 486mm
(19.1”) +50mm (2”) spikes H x 326mm
(12.8”) W x 438mm (19”) D
Drive Units : LF – PMC 10” 250mm
Carbon Fibre & Nomex™ Piston
HF – 27mm SONOLEX™ soft dome
Ferrofluid cooled MF – PMC75 SE 3”
75mm soft dome
Effective ATL™ Length : 2.4m 8ft
Frequency Response : 25Hz-25kHz
Impedance : 4 Ohm
Input Connectors : 3 pairs 4mm
sockets (tri-amp or tri-wire)
sensitivity : 89dB 1w 1m
Weight: 49kg (108lbs) – Stand 13kg
(28.7)
